| TECHNICIAL SPECIFICATIONS |
| Capacity | 1 kVA / 900 W |
| INPUT |
| Voltage | 208 / 220 / 230 / 240 Vac (settable via LCD) |
| Voltage range | 110 ~ 176 Vac (linear derating between 50% and 100% load); 176 ~ 280 Vac (no derating); 280 ~ 300 Vac (derating 50%) |
| Frequency | 40 ~ 70 Hz (auto-sensing) |
| Power factor | ≥ 0.99 |
| Bypass voltage range | -25% ~ +15% (settable) |
| THDI | ≤ 6% |
| OUTPUT |
| Voltage | 208 / 220 / 230 / 240 Vac (settable via LCD) |
| Voltage regulation | ± %1 |
| Frequency | 45 ~ 55 Hz or 55 ~ 65 Hz (synchronized range); 50 / 60 Hz ± 0.1 Hz (battery mode) |
| Waveform | Sinusoidal |
| Power factor | 0.9 |
| Total harmonic distortion (THDv) | ≤ 2% (linear load); ≤ 5% (non-linear load) |
| Output current crest factor | 3:1 |
| Overload | 105% ~ 125% for 1 min, 125% ~ 150% for 30 s, > 150% for 300 ms |
| BATTERIES |
| DC Voltage | 24V |
| Internal battery | 2x12V/9Ah |
| Charging current (max.) | 1A |
| Recharge Time | 90% capacity restored in 3 hours |
| SYSTEM |
| Efficiency | ≥ 90% (Mains mode)
≥ 85% (Battery mode)
≥ 95% (ECO mode) |
| Transfer time | Mains mode to battery mode: 0 ms
Inverter mode to bypass mode: 4 ms (typical) |
| Protection | Short-circuit, overload, overtemperature, battery discharge protection and fan testing protection |
| Communication | RS232 (standard), USB / RS485 / dry contacts / SNMP (optional) |
| Display | LCD + LED |
| Standards | EN 62040-1, EN 62040-2, EN 61000-3-2, EN 61000-3-3, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-2-2, IEC 62040-2, IEC 62040-1 |
| GENEL |
| Operating temperature | 0°C ~ 40°C |
| Storage temperature | − 25°C ~ 55°C (without battery) |
| Relative humidity | 0 ~ 95% (non-condensing) |
| Height | ≤ 1000 m, derating 1% for each additional 100 m |
| IP class | IP 20 |
| Noise level | ≤ 50 dB |
| Dimension (mm) HxWxD | 88x440x338 |
| Packed dimensions (mm) WxDxH | 201x545x485 |
| Weight (kg) | 12.3 |
| Gross weight (kg) | 14.3 |
